Dimension ES-3124 Ethernet Switch

5-4

System Status and Port Details

Table 5-2 Status: Port Details

LABEL DESCRIPTION

Port Info

Port NO. This field identifies the Ethernet port described in this screen.

Link This field shows whether the Ethernet connection is down, and the speed/duplex mode. It also

shows the cable type (Copper or Fiber) for the combo ports.

Status This field shows the training state of the ports. The states are FORWARDING (forwarding),

which means the link is functioning normally or STOP (the port is stopped to break a loop or
duplicate path).

LACP This field shows if LACP is enabled on this port or not.

TxPkts This field shows the number of transmitted frames on this port

RxPkts This field shows the number of received frames on this port

Errors This field shows the number of received errors on this port.

Tx KBs/s This field shows the number kilobytes per second transmitted on this port.

Rx KBs/s This field shows the number of kilobytes per second received on this port.

Up Time

This field shows the total amount of time the connection has been up.

Tx Packet

The following fields display detailed information about frames transmitted.

TX Packets

This field shows the number of good frames (unicast, multicast and broadcast) transmitted.

Multicast

This field shows the number of good multicast frames transmitted.

Broadcast

This field shows the number of good broadcast frames transmitted.

Pause

This field shows the number of 802.3x Pause frames transmitted.

Rx Packet

The following fields display detailed information about frames received.

RX Packets

This field shows the number of good frames (unicast, multicast and broadcast) received.

Multicast

This field shows the number of good multicast frames received.

Broadcast

This field shows the number of good broadcast frames received.

Pause

This field shows the number of 802.3x Pause frames received.

Control

This field shows the number of control received (including those with CRC error) but it does not
include the 802.3x Pause frames.

TX Collision

The following fields display information on collisions while transmitting.
