ZyXEL Communications ZyXEL Dimension ES-3124 - Manual (Page 264)

Dimension ES-3124 Ethernet Switch
A-2 Product Specifications
Chart 2 Performance and Management Specifications
Data Buffer 32MB
QOS
802.1p with 8 CoS per port. SPQ, WFQ, SPQ/WFQ combination capable.
Rule-based bandwidth control (ingress traffic metering/dropping 64Kb stepping)
Port-based egress traffic shaping, CIR/PIR supported.
Rule-based traffic mirroring
IGMP snooping per VLAN (IGMPv1/v2 16VLAN maximum, up to 256 groups)
MVR support.
802.3x flow control.
DSCP to 802.1p priority mapping via ACL.
VLAN
IEEE 802.1Q tag-based VLAN, 4094 Max
Port-based VLAN
No. of VLAN: 4K, 256 static maximum
GVRP for dynamic registration
Double tagging for VLAN stacking
Private VLAN for port isolation.
IEEE 802.1p Priority Queues Eight queues
Port Link Aggregation
IEEE802.3ad dynamic port trunking
6 groups
8 ports/group randomly selected
Port Security
Static MAC address filtering
MAC address learning limit
Multicasting Supports IGMP snooping
Broadcast Storm Supports broadcast storm control
Port Mirroring
All Ethernet, Gigabit, stacking and uplink ports support port mirroring
Rule-based port mirroring
Port-based mirroring
Support port mirroring per IP/TCP/UDP
Management
Web-based management
Console
Telnet
SNMP
Management Security
User ID/Password for Telnet and Web-based management authentication
Up to four administrators allowed
