Dimension ES-3124 Ethernet Switch

25-4

Maintenance

Click OK to see the screen as shown in Figure 25-6. Click OK again and then wait for the switch to restart. This
takes up to two minutes. This does not affect the switch’s configuration.

25.7 Command Line FTP

This section shows some examples of uploading to or downloading files from the switch using FTP commands.
First, understand the filename conventions.

25.7.1 Filename

Conventions

The configuration file (also known as the romfile or ROM) contains the factory default settings in the screens such
as password, switch setup, IP Setup, etc. Once you have customized the switch's settings, they can be saved back to
your computer under a filename of your choosing.

ZyNOS (ZyXEL Network Operating System sometimes referred to as the “ras” file) is the system firmware and has
a “bin” filename extension.

Table 25-1 Filename Conventions

FILE TYPE

INTERNAL

NAME

EXTERNAL

NAME

DESCRIPTION

Configuration File config

This is the configuration filename on the switch. Uploading the
config file replaces the specified configuration file system,
including your switch configurations, system-related data
(including the default password), the error log and the trace log.

Firmware

Ras

*.bin

This is the generic name for the ZyNOS firmware on the switch.

Example FTP Commands

ftp> put firmware.bin ras
This is a sample FTP session showing the transfer of the computer file " firmware.bin" to the switch .

ftp> get config config.cfg
This is a sample FTP session saving the current configuration to a file called “config.cfg” on your computer.

If your (T)FTP client does not allow you to have a destination filename different than the source, you will need to
rename them as the switch only recognizes “config” and “ras”. Be sure you keep unaltered copies of both files for
later use.

Be sure to upload the correct model firmware as uploading the wrong model firmware may

damage your device.

25.7.2

FTP Command Line Procedure

Step 1.

Launch the FTP client on your computer.

Step 2.

Enter “open”, followed by a space and the IP address of your switch.
