Dimension ES-3124 Ethernet Switch

Bandwidth Control

11-3

Table 11-1 Bandwidth Control

LABEL DESCRIPTION

Commit Rate

Specify the guaranteed bandwidth allowed in kilobits per second (Kbps) for the incoming traffic
flow on a port. The commit rate should be less than the peak rate. The sum of commit rates
cannot be greater than or equal to the uplink bandwidth.

Peak Rate

Specify the maximum bandwidth allowed in kilobits per second (Kbps) for the incoming traffic
flow on a port.

Egress Rate

Type the maximum bandwidth allowed in megabits per second (Mbps) for traffic going out of this
port.

Apply Click

Apply to save your changes back to the switch.

Cancel

Click Cancel to reset the fields to your previous configuration.
