Dimension ES-3124 Ethernet Switch

Bandwidth Control

11-1

Chapter 11

Bandwidth Control

This chapter shows you how you can set the maximum bandwidth allowed for traffic flows on a port

using the Bandwidth Control setup screens.

11.1 Introduction to Bandwidth Control

Bandwidth control means defining a maximum allowable bandwidth for incoming and/or out-going traffic flows
on a port.

11.1.1

CIR and PIR

The Committed Information Rate (CIR) is the guaranteed bandwidth for the incoming traffic flow on a port. The
Peak Information Rate (PIR) is the maximum bandwidth allowed for the incoming traffic flow on a port when
there is no network congestion.

The CIR and PIR should be set for all ports that use the same uplink bandwidth

.

If the CIR is reached, packets are

sent at the rate up to the PIR. When network congestion occurs, packets through the ingress port exceeding the
CIR will be marked for drop.

The CIR should be less than the PIR.

The sum of CIRs cannot be greater than or equal to the uplink bandwidth.

11.1.2

Bandwidth Control Setup

Click Advanced Application and then Bandwidth Control in the navigation panel to bring up the screen as shown
next.
