Dimension ES-3124 Ethernet Switch
4-4
Introducing the Web Configurator
Table 4-2 Web Configurator Screen Sub-links Details
BASIC SETTING
ADVANCED
APPLICATIONS
ROUTING PROTOCOL
MANAGEMENT
Status
Configuration
Port Authentication
RADIUS
802.1x
Port Security
Access Control
SNMP
Logins
Service Access Control
Remote Management
Queuing Method
Classifier
Policy Rule
VLAN Stacking
Multicast
DHCP Relay
The following table summarizes these sub-links in the navigation panel.
Table 4-3 Navigation Panel Sub-link Descriptions
LABEL DESCRIPTION
Basic Setting Screens
System Info This link takes you to a screen that displays general system and hardware monitoring
information.
General Setup This link takes you to a screen where you can configure general identification information
about the switch and login precedence.
Switch Setup This link takes you to a screen where you can set up global switch parameters such as
VLAN type, MAC address learning, GARP and priority queues.
IP Setup This link takes you to a screen where you can configure the IP address, subnet mask
(necessary for switch management) and DNS (domain name server).
Port Setup This link takes you to screens where you can configure settings for individual switch ports.
Advanced Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding
This link takes you to screens where you can configure static MAC addresses for a port.
These static MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
