Dimension ES-3124 Ethernet Switch

Command Examples

31-15

egress set

where

Sets the outgoing traffic port list for a port-based VLAN.

An example is shown next.

Enable port-based VLAN tagging on the switch.

Enable ports one, three, four and five for configuration.

Set the outgoing traffic ports as the CPU (0), seven (7), eight (8) and nine (9).

Figure 31-30 egress set Command Example

31.8.12 qos

priority

Syntax:

qos priority <0 .. 7>

where

<0 .. 7>

Sets the quality of service priority for an interface(s).

An example is shown next.

Enable ports one, three, four and five for configuration.

Set the IEEE 802.1p quality of service priority as four (4).

Figure 31-31 qos priority Command Example

31.8.13 name

Syntax:

name

where

string>

Sets a name for your port interface(s).

An example is shown next.

Enable ports one, three, four and five for configuration.

Set a name for the interfaces.

ras(config)# vlan-type port-based

ras(config)# interface port-channel 1,3-5

ras(config-interface)# egress set 0,7-9

ras(config)# interface port-channel 1,3-5

ras(config-interface)# qos priority 4
