Dimension ES-3124 Ethernet Switch

Cluster Management

27-3

Table 27-2 Cluster Management Status

LABEL DESCRIPTION

Status This field displays:

o Online (the cluster member switch is accessible)

o Error (for example the cluster member switch password was changed or the

switch was set as the manager and so left the member list, etc.)

o Offline (the switch is disconnected - Offline shows approximately 1.5 minutes

after the link between cluster member and manager goes down).

27.2.1

Cluster Member Switch Management

Go to the Clustering Management Status screen of the cluster manager switch and then select an Index hyperlink
from the list of members to go to that cluster member switch's web configurator home page. This cluster member
web configurator home page and the home page that you'd see if you accessed it directly are different (see Figure
27-3
).

Figure 27-3 Cluster Member Web Configurator Screen

Uploading Firmware to a Cluster Member Switch

You can use FTP to upload firmware to a cluster member switch through the cluster manager switch as shown in
the following example.

Cluster Manager

Menus

Cluster Member

Menus
