6-12

IMACS System Release 5.1.6

Data Cards

Model No.

Running Head

PM-IOR Card User Screens and Settings

PM-IOR Card

Table 6-3. Test Screen Actions

Table 6-4. Test Screen Option Settings and Defaults

BERT

The Bit Error Rate Tester (BERT) sends a data pattern and measures the bit error rate (BER)
on the selected HSU port. The patterns that can be selected are off, mark (1111), space (0000),
1:1 (1010 alternating), 1:7 (0100-0000), 511 (511 test pattern), qrss (quasi-random signal
source), and 2047 (2047 test pattern).

Action

Function

Save

Saves changes to settings.

Undo

Returns all settings to the last saved state.

Refresh

Updates certain time-related information fields that are not automatically
updated (i.e., performance and test data).

InsertErr

Allows you to manually insert a single error into the clear data signal.

Clear

Clears the Test Screen and resets all counters to zero.

Main

Returns to the PM-IOR Card Main Screen. If changes are made to settings and
not saved, you will be prompted to save or lose changes.

Parameter

User Options

Default

BERT

off mark space 1:1 1:7 511 qrss
2047 ds0 ff 7e 32 40 ocu-a csu-a
dsu-a csu1a csu2a

off

CTS
