5-42 IMACS System Release 5.1.6 Data Cards
Model No. Running Head BRI Card User Screens and Settings BRI Card
Figure 5-19. BRI U*8 and BRI-SC U*8 Cards Performance Data Screen
Table 5-26. BRI U*8 and BRI-SC U*8 Cards Performance Data Screen Actions
Table 5-27. BRI U*8 and BRI-SC U*8 Card Threshold Monitoring Screen Actions
Action Function
Refresh Performance data is not automatically updated on screen. Press “r” to show
updated data.
Clear Clears the Performance Screen and resets all counters to zero.
pgUp Allows the user to go to previous page. If already in page 1 this option does
not have any effect.
pgDn Allows the user to go to the next page. If already in page 3 this option does
not have any effect.
Main Returns to the BRI Card Main Screen. If changes are made to settings and not
saved, you will be prompted to save or lose changes.
Action Function
Refresh Test data is not automatically updated on screen. Press “r” to show updated
data.
Main Returns to the BRI Card Main Screen. If changes are made to settings and not
saved, you will be prompted to save or lose changes.
