Data Cards IMACS System Release 5.1.6 5-29
BRI Card BRI Card User Screens and Settings
Notes:
1. Not user-selectable; the DTE INTF TYPE is automatically detected.
2. The DCD OFF DELAY is n/a if the DCD OPTIONS selection is on or off.
If r_rts is selected, the options are 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70,
75, or 80 bits.
3. The CTS ON DELAY is n/a if the CTS OPTIONS selection is on or off.
If l_rts is selected, the CTS ON DELAY is measured either in bits or milliseconds. The
options are 0, 10, 20, 30, 40, 50, or 60 bits, or 10, 20, 30, 40, 50, 100, or 250
milliseconds.
4. This option is always disabled.
DTE INTF TYPE
The DTE Interface Type indicates the type of connector on the rear panel of the NTU. For the
2560, the selection is v.36. For the 2561, the selection is v.24. This parameter is automatically
detected and is not user-selectable.
DTE SYNC/ASYN
This option selects the transmission mode. Synchronous transmission is indicated with the
sync option (which is the default). Asynchronous transmission has four options: asy8 (8-bit
byte), asy9 (9-bit byte), asy10 (10-bit byte), or asy11 (11-bit byte). These options include the
start bit, stop bit, parity bit and data bits.
DTE DATA RATE sync: 1.2k 2.4k 4.8k 9.6k 14.4k 19.2k 28.8k 32k
38.4k 48k 56k 64k 72k 128k
asy8/asy9/asy10/asy11: <1.2k 1.2k 2.4k 4.8k 9.6k
14.4k 19.2k 28.8k 38.4k ---
CLOCK MODE int int
DCD OPTIONS off on r_rts on
DCD OFF DELAY n/a 5-80 2 n/a
DSR OPTIONS off on on
CTS OPTIONS off on l_rts on
CTS ON DELAY n/a 0-60 bits 10-250 msec 3 n/a
ASYN BAUDRATE offset exact offset
RI INDICATION off on off
RL LINE dis 4 dis
LL LINE dis ena ena
NTU CONSOLE dis ena ena
