Data Cards IMACS System Release 5.1.6 5-9
BRI Card BRI Card User Screens and Settings
START (h)
The Start parameter allows you to set the time (in hours) the sealing current is to be applied to
the port selected. The values are 0 to 24. Selection of 0 will start the sealing current as soon
as the changes are saved. Selection of any other number from 1 to 24 turns on the sealing
current that many hours from the time selected (e.g., 6 will turn on the current in six hours).
DURATION (m)
The Duration parameter allows you to set the duration of time (in minutes) the sealing current
is to be applied to the port selected. The values are 1 to 60.
REPEAT
The Repeat parameter allows you to repeat the application of sealing current to the line of the
port selected. The values are yes and no.
REP. EVRY (h)
The Repeat Every parameter allows you to set the time (in hours) the sealing current is to be
repeated on the port selected. The values are 0 to 24. Selection of any number from 1 to 24
repeats turning on the sealing current that many hours (e.g., 1 will repeat the current every
hour).
Note: To turn on and sustain sealing current, set DURATION (m) to 60, REPEAT to yes, and
REP. EVRY (h) to 1.
5.3.3 BRI-ST*8 Card Description (826270)
The BRI-ST*8 (826270) card is designed to support "S/T" 4-wire interface applications. It
also supports both internal and external phantom power arrangements. Jumpers are available
to select terminations on the receive and transmit sides individually.
The jumper defaults are as follows:
• Phantom Power - OFF
• Phantom Power Source - Internal IN
• 100 Ohm Term - Rcv IN
