COURIER HIGH SPEED MODEMS

Alphabetical Command Summary C-3

DIP Switch 9 Response to +++
OFF

Modem goes on hook (hangs up), sends NO
CARRIER result code (factory setting)

ON

Modem maintains connection (Online-Command
mode), sends OK result code

The factory setting (OFF) forces an automatic disconnect when
you issue +++. An advantage of this is that you are not likely
to inadvertently run up an all-night phone bill.

Set DIP switch 9 ON if you want the modem to respond to +++
by entering Online-Command mode, enabling it to execute
commands and return online. (See the O command later in this
appendix.)

>

If you know the modem you are calling is frequently busy,
include the Repeat command in the Dial string, as follows:

AT > DT 1234567 or
AT DT 1234567 >

The modem enters Repeat mode, dials the number, waits 60
seconds for a carrier (default), and hangs up. Then after a two-
second pause, it redials.

The cycle continues until the modems connect or the modem
reaches a maximum of 10 attempts.

A

Force Answer mode when the modem hasn't received an
incoming call.

A/

Re-execute the last issued command. A/ doesn't take the AT
prefix or a Carriage Return, and can be used to redial.

A>

This command combines the features of both the A/ and >
commands. The modem enters Repeat mode and redials the
Dial string in the command buffer. Like the A/ command, A>
does not take the AT prefix or a Carriage Return.

AT

Attention command prefix. Use AT alone to test for the OK
result code. AT must prefix all commands except A/, A> and
+++.

Any

Terminate the current dialing operation resulting from an

key

issued Dial command; terminate Repeat mode (> or A>).
