7 Appendix
Example Connection for 38C2
Vcc
5.1k
8MHz
15pF
15pF
Vss
P3 3 /RxD 2 /(LED 3 )
P3 2 /TxD 2 /(LED 2 )
X IN
X OUT
CNVss
RESET
P3 1 /S CLK2 /(LED 1 )
P3 0 /S RDY2 /(LED 0 )
Vcc
5.1k
0.1uF
Vcc
5.1k
Vcc
P4 1 /AN 1
GND
Vcc
RxD
TxD FLAT Cable Connection
USB Monitor Board
RESET
EPM
BUSY
SCLK
CE
CNVss
1
10
9
8
7
6
5
4
3
2
p3_2
p3_3
Port Pin No Signal
TxD
GND
RxD
Vcc
Connector Type
HIF3FC-10PA-2.54DSA
10-Pin Connector assign
CE
BUSY
SCLK
EPM
RESET
CNVss
p3_0
p3_1
2
4
6
8
10 9
7
5
3
1
Vcc
Note: When the flash mode control pins are used for user' s application circuit.
Refer to the 38C2 group (A version) datasheet for operation details.
AVss
5.1k
User Reset Signal
