5 Using the KD
5.3 Memory Map Limitations
Table 5-2 and Table 5-3 list the ROM/RAM areas which the monitor program uses. Figure
5-12 shows the memory map.
Table 5-2 ROM/RAM areas (1)
Group MCU ROM/RAM XXXXXh YYYYYh ZZZZZh
M16C/10 M30102F3 24K/1K 780h 7FFh 0FA000h
M16C/1N M301N2F8 64K/3K F80h FFFh 0F0000h
M16C/24 M30245FC 128K/10K 2B80h 2BFFh 0E0000h
M30262F3 24K/1K 780h 7FFh 0FA000h
M30262F4 32K/1K 780h 7FFh 0F8000h
M30262F6 48K/2K B80h BFFh 0F4000h
M16C/26
M30262F8 64K/2K B80h BFFh 0F0000h
M30260F3A 24K/1K 780h 7FFh 0FA000h
M30260F4A 32K/1K 780h 7FFh 0F8000h
M30260F6A 48K/2K B80h BFFh 0F4000h
M30260F8A 64K/2K B80h BFFh 0F0000h
M30263F3A 24K/1K 780h 7FFh 0FA000h
M30263F4A 32K/1K 780h 7FFh 0F8000h
M30263F6A 48K/2K B80h BFFh 0F4000h
M16C/26A
M30263F8A 64K/2K B80h BFFh 0F0000h
M30280F6 48K/4K
1380h 13FFh 0F4000h
M30280F8 64K/4K 1380h 13FFh 0F0000h
M30280FA 96K/8K 2380h 23FFh 0E8000h
M30281F6 48K/4K 1380h 13FFh 0F4000h
M30281F8 64K/4K 1380h 13FFh 0F0000h
M16C/28
M30281FA 96K/8K 2380h 23FFh 0E8000h
M30290F8 64K/4K 1380h 13FFh 0F0000h
M30290FA 96K/8K 2380h 23FFh 0E8000h
M30290FC 128K/12K 3380h 33FFh 0E0000h
M30291F8 64K/4K 1380h 13FFh 0F0000h
M30291FA 96K/8K 2380h 23FFh 0E8000h
M16C/29
M30291FC 128K/12K 3380h 33FFh 0E0000h
M30620FCA 128K/10K 2B80h 2BFFh 0E0000h M16C/62A
(62M) M30624FGA 256K/20K 5380h 53FFh 0C0000h
M30622F8P 64K/4K 1380h 13FFh 0F0000h
M30623F8P 64K/4K 1380h 13FFh 0F0000h
M30620FCP 128K/10K 2B80h 2BFFh 0E0000h
M30621FCP 128K/10K 2B80h 2BFFh 0E0000h
M30624FGP 256K/20K 5380h 53FFh 0C0000h
M30625FGP 256K/20K 5380h 53FFh 0C0000h
M30626FHP 384K/31K 7F80h 7FFFh 0A0000h
M30627FHP 384K/31K 7F80h 7FFFh 0A0000h
M30626FJP 512K/31K 7F80h 7FFFh 080000h
M16C/62P
M30627FJP 512K/31K 7F80h 7FFFh 080000h
M16C/62N M3062GF8 64K/8K 2380h 23FFh 0F0000h
