5 Using the KD
5.1.2 Starting the KD
1) From the Start menu, choose Programs -- RENESAS-TOOLS – KD30 V.*.**
Release* -- KD30 to start the KD. When the KD starts, the screen shown in Figure 5-2
appears. If the screen appears, click the button and choose MCU File.
Note: In the case of M16C/80 and M32C/80, start KD3083.
Figure 5-2 Init screen-1
2) Next, the Select MCU File screen on Figure 5-3 will be displayed. For KD30, select
the category folder of MCU to be used from the MCU category folder of the McuFiles
folder and open it. For KD3083, open the MCU File from the McuFiles folder.
Figure 5-3 Select MCU File screen
50
