1 Contents of Product
1.4 Board Specification
Table 1-5 shows the USB Monitor Board Specification. When saving these products, put
them into the conductive bag. Store them into the container box which is used for shipping
as possible
Table 1-5 USB Monitor Board Specification
Item Description
Debug formula Monitor program formula
ROM size: Approx. 1600 byte
* In the case of R8C/Tiny Series, 2K byte
RAM size: 128 byte
* In the case of M16C/80 Group, 256 byte
* In the case of M32C/80 Series, 256 byte
* In the case of R8C/Tiny Series, not used
Operation frequency: 700KHz or above
(Note1)
Operation mode: Single chip mode
Monitor program
Software break: 2 points to 8 points (Note2)
USB microcomputer M37641F8HP (8 bit USB flash microcomputer)
USB interface (J1) USB2.0 full speed
Synchronous serial Interface Target interface (J3)
Starter kit and 10 pin connector for target board connection
4.75V to 5.25V
(USB bus-powered supply or target supply enabled)
Operation voltage
3.0V to 3.6V (supply from target is necessary) (Note3)
Power consumption Max.50mA
Board size 70mm x 29mm
Temperature: 25±5°C (no corrosive gas)
Use environment condition
(at the time of operation)
Humidity: no condensation
Temperature: 25±5°C (no corrosive gas) Use environment condition
(at the time of storage)
Humidity: no condensation
Note 1: Maximum operating frequency is dependent on the MCU.
Note 2: Software break numbers are dependent on the address match circuit numbers
are built-in MCU.
Note 3: When operating in 3.3V, supply power from the target board. In this case, it is not
possible to change the FoUSB firmware. When the model name of the
microcomputer to be used is changed, remove the target board, supply the USB
bus-powered and rewrite the firmware.
7
