3 Installing
5) Next, the Hardware Installation screen is displayed, click the button (Note) .
Note: Microsoft has advocated authentication of the USB drivers to the USB vendors in the
Microsoft® Windows® XP and Windows®-based operating systems released after Microsoft®
Windows® XP. This is aimed at elimination of illegal drivers and improvement of host computer
(PC). Renesas USB Drivers are not authenticated by Microsoft, but we provide them baased
on the sufficient examination.
6) Click the button. Windows system recognizes USB Monitor Board (for FoUSB Driver).
Recognition of USB Monitor Board for FoUSB Driver is completion.
7) Separate USB Monitor Board from host computer (PC).
8) Finally remove the cover of USB Monitor Board and set the MCU Mode Pin (JP1: MCU Mode)
as “Open”.
22
