4 Using the FoUSB

4. Using the FoUSB

4.1 Using the FoUSB (Flash-over-USB)

4.1.1 Before Starting the FoUSB

1) Check to see that the FoUSB is installed in your host computer (PC).

2) Check to see that PC, USB Cable, USB Monitor Board, Flat Cable and Target Board

are firmly connected. (See Figure 4-1)

3. USB Monitor Board

4. Flat Cable

1. USB Cable

2. Target Board

5. Target MCU

Figure 4-1 connect-1

27
