Renesas M16C FAMILY User Manual
Page 76
6 Troubleshooting
8) Connect USB Monitor Board (Board) with your host computer (PC).
9) Since firmware has downloaded normally if a Power indicator (D4: Status) is lighting
and the Status indicator is blinking as shown in the following figure, FoUSB and KD
(KD30, KD3083) can be used.
lighting
blinking
10) Separete USB Monitor Board (Board) from PC and attach a cover in the USB Monitor
Board (Board).
11) Now you've finished compulsive downloading the firmware.
73
