5 Using the KD
3) The Init screen of the Figure 5-4 opens when it is done after a MCU File is chosen.
Choose “USB” as the communication interface and click the button.
Figure 5-4 Init screen-2
NOTICE: Precautions on KD3083 Emulation Memory
The address allocated to the Emulation Memory cannot be debugged in the KD3083.
Therefore, allocate the Emulation Memory to the address which is not used in debug.
The address in the Emulation Memory can be
modified by the bank address (default vale: F0).
The high-order 24 to 17 bits of the address will be
a bank address.
Figure 5-5 Emem screen (KD3083 only)
The following section describes the address modification of the Emulation Memory as
an example of the M3087BFLGP (M32C/87 Group microcomputer).
51
