Renesas M16C FAMILY User Manual
Page 23
3 Installing
6) Click the
Driver).
Recognition of USB Monitor Board for USBMON Driver is completion.
3.4.2 Recognition of USB Monitor Board 2 (for FoUSB Driver)
1) Remove the cover of USB Monitor Board and make a USB Monitor Board (Board) the following
setup, before connecting USB Monitor Board to your host computer (PC). If a setup is completed,
attach a cover in a USB Monitor Board (Board).
Power Source Supply Selector (S1: Power Mode): USB side
MCU Mode Pin (JP1: MCU Mode): Shorted
Shorted
USB side
Figure 3-3 Setup of USB Monitor Board (Board)
20
