5 Using the KD
5.1.7 Software Break Method
When executing the software break, the software break can be set as the place which
has "-" in "BRK" in Program Window screen. The KD Main screen is as Figure 5-10.
Software break point
Figure 5-10 Software Break
5.1.8 Reset Execution
User Program is in the same status as immediately after download. Click the "Reset"
button (Figure 5-6, D) on the KD Main screen.
5.1.9 KD Completion
1) Before completing a KD, stop the User Program.
2) Next, select "File -- Exit" menu in the KD Main screen. When the Exit menu is
selected opens, click "OK" button. If "Cancel" is clicked, the KD is not completed.
57
