7 Appendix
7. Appendix
7.1 USB Monitor Board
7.1.1 Board Specifications
Figure 7-1 list Board specifications of USB Monitor Board.
J3:10-Pin connector
(Flat Cable)
J1:USB connector
(USB Cable)
LED’s:
D2(Red) - Stop
D3(Green) - Run
D4(Yellow) - Status
D1(Red) - Power
M37641F8
USB MCU
J2:UART Interface
JP1:MCU Mode Pin
(Boot/User)
S1:Power Source Supply
Selector
Figure 7-1 USB Monitor Board (Board specifications)
79
