Renesas M16C FAMILY User Manual
Page 75
6 Troubleshooting
4) On the Chip Selection screen, select your MCU and download a firmware to the USB
MCU.
(2) Click here
(1) Select your MCU
5) If download of firmware is completed to USB MCU, since the completion screen of
download will be displayed, click the
6) End FoUSB and separate a USB Monitor Board (Board) from your host computer
(PC).
7) Make Open JP1 (MCU Mode Pin) of the USB Monitor Board (Board).
Open
72
