C O M M A N D L I N E I N T E R F A C E
Command Summary
350-7951 Quadra User’s Guide 77
.
. .
.
.
SETTINGSIMPORT [filename] This command enables you to restore or set
system settings (or clone a new system) to match
the configuration of a different
Quadra unit.
The command accepts the text file created using
the
SETTINGSEXPORT command. If the
filename is not specified, the default
filename“export.txt” is assumed.
Use the following procedure to import settings
from your PC.
• Log in to Quadra using FTP from your
PC.
• Enter the user name “ rgb ” (lower case)
and the password “ spectrum .”
•
Type the command “put ” to
place the file into
Quadra memory.
( is the name of the file
created using the
SETTINGSEXPORT
command).
• Type “quit” to log out of Quadra ’s FTP
server.
• From the Telnet or serial port, issue the
command SETTINGSIMPORT
. Note that if you use the
default filename “export.txt” you do
not need to specify the filename.
See also: SETTINGSEXPORT .
STATus (none) Returns details about the current graphics input
signals that are applied to each
Quadra graphics
input.
SYStemReSeT (none) Causes the Quadra system to reset.
TestPattern
[SNOW | RANDOM |
DVI1 | RAMPS | GRID |
HBARS | BARS | OFF] Turns on the designated color bar test pattern for
the specified output channel. Use the OFF
argument to turn the test pattern off.
Default: OFF
UpdateFirmWare (none) Loads new firmware into Quadra . This is a two
step process.
• The new firmware must be first be
downloaded to
Quadra.
• Load the new firmware use the UFW
command.
• Refer to Appendix D for further
information on updating firmware.
VERsion (none) Returns firmware, hardware, and bootcode
revision information.
Table 4-15. MIscellaneous Commands Descriptions(Continued)
Command Arguments Description
