F I R M W A R E U P G R A D E S A N D T R O U B L E S H O O T I N G
System Troubleshooting
350-7951
Quadra User’s Guide
113
.
. .
.
.
No text on a terminal
•
To see your own typed entries, enable the echo mode when
using an ASCII terminal (or terminal emulation program)
to control the system from the RS-232 port.
•
Use the “
” command to enable or disable the echo
mode.
•
When using an application program running on a computer
to control
Quadra
over the RS-232 port, you may need to
disable the echo mode.
•
Check baud rate and protocol settings.
•
Check that cables are in good condition and connected
correctly.
Unreliable control of the
Quadra
from the RS232
port.
•
See the recommendation immediately above. You may
need to disable “
•
Check that the “
” for the
Quadra
and your
console device are set to the same speed.
Unable to connect to the
Quadra
over the network.
•
Check that the
Quadra
is connected to the network using
a standard Ethernet cable.
•
Check that you are using the correct IP address.
•
If you are unable to connect and are sure that IP address is
correct, check the Subnet mask and make sure that it is
suited to your network configuration.
•
If you believe the IP address and Subnet mask are correct
but you still cannot connect, check that this is not a
duplicate IP address. Use the IP “ping” command from
the Windows
®
command window, and see if there is a
response. If there is a response, turn off
Quadra
and ping
the IP address again. If there is still a response, a duplicate
address exists.
Unable to connect to
Quadra
directly from a
PC (peer to peer
connection).
•
Check that
Quadra
is connected to the PC using an
Ethernet crossover cable. A suitable cable is the Belkin
Part # A3X126-07.
•
Check that you are using the correct IP address.
•
If you are unable to connect and are sure that the IP
address is correct, check the IP settings of your PC. Many
PCs are set to work with a DHCP server which is not
present when connecting directly to
Quadra.
•
If you believe that
Quadra
’s IP address is correct and
your PC has a valid IP address, but you still cannot
connect, check that this is not a duplicate IP address. Use
the IP “ping” command from the Windows command
window, and see if there is a response. If there is a
response, turn off
Quadra
and ping the IP address again.
If there is still a response, your PC has been set with the
same address as the
Quadra
.
Table D-1.
Troubleshooting Guide(Continued)
Symptom
Recommendations
