TE C H N I C A L S P E C I F I C A T I O N S
General Specifications
350-7951 Quadra User’s Guide 118
.
. .
.
.
S-VIDEO INPUT
. . . . . . . . . SPECIFICATIONS
The table below lists S-Video input specifications:
GRAPHIC OUTPUT
. . . . . . . . . SPECIFICATIONS
The table below lists high resolution graphic output specifications:
Table E-5. S-Video Input Specifications
Parameter Specification
Format S-Video (NTSC RS-170A or PAL CCIR 624)
Number Up to four S-Video channels, or the user may use the S-Video channel for
four additional composite video inputs (Composite2).
Input sampling All inputs sampled as 3:2 pixels (CCIR 601 sampling)
Video levels 0.5 to 2.0V peak-to-peak; 1.0V peak-to-peak nominal
Sync levels 0.3 to 0.6V peak-to-peak
Connector type 4-pin mini-DIN
Table E-6. Graphic Output Specifications
Parameter Specification
Analog
Analog output level Nominal 0.7V. pk to pk (excluding sync)
Output impedance 75 ohms
Sample rate Up to 162 Msample/sec
Sync type Available sync types:
• 3 wire (sync on green),
• 4 wire (separate composite sync)
• 5 wire (separate H and V sync)
Sync level 0.3V p-p (3wire), 5V p-p max (4 and 5 wire)
DVI
Max bandwidth DVI single link (1.65Gbps)
Connector type DVI-I MicroCross Integrated Digital / Analog Connector
