I N S T A L L A T I O N A N D S E T U P
Rear Panel
350-7951 Quadra User’s Guide 13
.
. .
.
.
can connect this output to a DVI-capable monitor or an analog RGB
monitor.
7) Graphic Output 2
One DVI-I multi-pin connector is provided for Graphic Output 2,
which is identical to Graphic Output 1.
8) Graphic Output 3
One DVI-I multi-pin connector is provided for Graphic Output 3,
which is identical to Graphic Output 1.
9) Graphic Output 4
One DVI-I multi-pin connector is provided for Graphic Output 4,
which is identical to Graphic Output 1.
10) RS-232 Serial Port
One 9-pin female D-Sub connector is provided for local RS-232
control from an external device. Please note:
~ Use this connector when the controlling device is physically
close to Quadra, and control across a network is not required.
~ Connection to a PC, external controller or serial terminal can
be made using this connector.
11) Ethernet Port
One 10/100 Base-T Ethernet (RJ-45 connector) is provided for control
over a network or from a local computer using peer-to-peer
communication. Using a standard Ethernet cable, you can connect
directly to a local area network (LAN). Use this port when control
over a network is a requirement.
Note You can control Quadra by using either the RS-232 port or
the 10/100 Base-T Ethernet port. Both ports can be
connected at the same time.
