C O M M U N I C A T I O N S S E T U P
IP Address Setup
350-7951 Quadra User’s Guide 93
.
. .
.
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I P A D D R E S S S E T U P
The following topics are discussed in this section:
• Introduction to IP Addresses
• IP Address Setup via Serial Port
• IP Address Setup via Ethernet
INTRODUCTION TO
. . . . . . . . . IP ADDRESSES
When connecting systems via Ethernet, the setup of communications
parameters is automatic. However, because this is a network connection, a
unique address (known as the IP address) is required.
For proper operation, Quadra requires a fixed IP address (also known as a
“static” IP address). At the factory, Quadra is programmed with a default IP
address (
192.168.1.200 ), but this address must be changed if you want to use
your Quadra on a network.
S
Recommendation : If you want to use Quadra on a Local Area
Network (LAN), change the unit’s IP address before putting it on the
network. This can be accomplished in one of two ways:
~ Use the serial port to change the unit’s IP address. Refer to
the “
IP Address Setup via Serial Port ” section below.
~ Connect Quadra directly to a PC using Quadra’s Ethernet
port. Refer to the “
IP Address Setup via Ethernet ” section
for details.
IP ADDRESS SETUP
. . . . . . . . . VIA SERIAL PORT
Use the following steps to change Quadra’s IP address using the serial port:
1. Connect Quadra as outlined in the “ RS-232 Serial Control Setup ”
section in Chapter 2.
2. In the Hyperterminal window, type:
IPADDR
... and press Enter .
Quadra responds with the current IP address. Make a note of the
address before proceeding with the next step.
3. Type IPADDR followed by a space, and the new IP address (as
provided to you by your network administrator).
S
Example : If the new IP address is 192.168.100.15 , type:
IPADDR 192.168.100.15
... and press Enter .
Important Consult your network administrator to obtain a valid IP
address before commencing the network setup procedure.
