TE C H N I C A L S P E C I F I C A T I O N S
General Specifications
350-7951 Quadra User’s Guide 116
.
. .
.
.
SYSTEM
. . . . . . . . . CHARACTERISTICS
The table below lists Quadra system characteristics:
DIGITAL INPUT
. . . . . . . . . SPECIFICATIONS
The table below lists high resolution graphics digital input specifications:
Table E-1. System Characteristics
Parameter Specification
Number of channels Four channels, each with up to four user-selectable types of inputs.
Input types The user may select between the following types for each input channel:
• RGB / YPbPr component (HDTV)
• Composite video
• S-Video
• DVI (optional)
# of outputs per channel Each output connector is dedicated to a specific input channel.
Each output connector supports 1 x analog or 1 x DVI output
Horizontal scan rate 12 kHz to 125 kHz (non interlaced)
Frame rate (Refresh rate) Up to 200 Hz
Resolution 640 x 350 to 1600 x 1200 pixels
Table E-2. Optional Digital Input Specifications
Parameter Specification
Type DVI - Single link
Maximum bandwidth 1.65 Gbps
Connector type DVI-I Integrated digital/analog connector, MicroCross (Molex #74320)
