I N S T A L L A T I O N A N D S E T U P
System Timing
350-7951 Quadra User’s Guide 26
.
. .
.
.
7. With the upper-left corner properly adjusted, adjust the lower-right
corner next by using the following keyboard controls. The goal is to
position this corner for maximum image visibility.
I = move up J = move left
M = move down L = move right
8. To exit the function, type q . This returns the system to the “normal”
command mode of operation.
9. Repeat steps 5 through 7 for the selected input. This repetition is
necessary to accurately fine-tune the timing parameters.
10. Use the Input Name function to name the input source, up to 23
alphanumeric characters in length. Spaces are not allowed in the
name, but underscores and upper/lower case characters are OK. Type:
INN Enter
S
Example: To name input 1 “PowerPoint_1,” type:
INN 1 PowerPoint_1
11. Use the Input Save function to store the selected input’s parameters in
one of 61 slots in the Input List. These settings are recalled whenever
the signal is reapplied to the Quadra. Type:
INS <100 ... 160> Enter
S
Example: To save input 1 in Input List slot 101, type:
INS 1 101
This completes the procedure for adjusting, naming and saving the
selected input.
12. Repeat steps 4 through 11 for all remaining Quadra inputs.
Note These commands are all upper case.
