Chapter 1 BayStack 420 Switch 29
Using the BayStack 420 10/100/1000 Switch
Table 2 BayStack 420 Switch LED descriptions
Label Type Color State Meaning
Power
On Power status Green On DC power is available to the switch’s internal circuitry.
Off No AC power to switch or power supply failed.
Cascade
Up Stack mode Off The switch is in standalone mode.
Green On The switch is connected to the upstream unit’.
Cascade
Down Stack mode Off The switch is in standalone mode.
Green On The switch is connected to the downstream unit.
Base Base mode Green On The switch is configured as the stack base unit.
Off The switch is not configured as the stack base unit (or is
in standalone mode).
Amber Due to a stack error, the unit is unable to maintain the
stack connection.
10/100
Link/
10/100 Mb/s
port speed
indicator Green On The corresponding port is set to operate at 100 Mb/s, and
the link is good.
Amber On The corresponding port is set to operate at 10 Mb/s, and
the link is good.
Off The link connection is bad, or there is no connection to
this port.
Activity Port activity Green Blinking Indicates network activity for the corresponding port. A
high level of network activity can cause the LEDs to
appear to be on continuously.
HD/FD Duplex Mode Green On/
Off
The port is configured to full duplex.
The port is configured to half duplex.
