186 Appendix B Installing a Gigabit Interface Converter (GBIC)
209418-A
Table 50 describes standards, connectors, cabling, and distance for the Model
1000BASE-SX GBIC.
1000BASE-LX
The Model 1000BASE-LX GBIC provides 1000BASE-LX (1300 nm,
wavelength, Gigabit Ethernet) connectivity using SC duplex fiber connectors. The
long wavelength optical transceivers used in the LX model provide variable
distance ranges using both multimode and single-mode fiber optic cabling. The
Model 1000BASE-LX GBIC supports full-duplex operation only
.
Table 50 Model 1000BASE-SX GBIC specifications
Type Specifications
Standards Conformity to the following standards:
802.3z, 1000BASE-SX
Connectors Duplex SC fiber optic connector
Cabling 62.5 µm MMF optic cable
50 µm MMF optic cable
Distance 902 ft. (275 m) using 62.5 µm MMF optic cable
1804 ft. (550 m) using 50 µm MMF optic cable
Wavelength 850 nm
Optical budget 7 dB
Laser Transmitter Characteristics
Minimum launch power -10 dBm
Maximum launch power -4 dBm
Receiver Characteristics
Minimum receiver sensitivity -17 dBm
Maximum input power 0 dBm
