ProSafe Dual Band Wireless Access Point WNDAP330 Reference Manual
1-10 Introduction
v1.0, May 2008
Rear Panel
The WNDAP330 rear panel functions are described below:
1. Left, Middle, and Right Detachable Antenna
The WNDAP330 provides three detachable antennas (two dipole and one patch).
2. Restore to Factory Defaults Button
The restore to default button located between the Ethernet RJ-45 connector and the power
socket restores the WNDAP330 to the factory default settings.
3. Serial Console Port
Male DB-9 serial port for serial DTE connections.
Figure 1-2
1
3 4 5 1 2
1
