Operation
3-37 3170-A2-GB20-20 December 1996
E1 DSU/CSU User Interface
Access Security
NOTE
This page of the manual is self-
supporting and can be removed to
prevent unwanted knowledge of the
security access levels and their
selection.
The user interface access security option allows you to
limit access to the E1 DSU/CSU to display-only and
non-intrusive functions.
Level 1 (Lvl1) access security allows access to all
functions available through the menu tree. This is the
default setting.
Level 2 (Lvl2) access security restricts access to only
those functions that cannot affect the operation of the E1
DSU/CSU in any way. At this level,
•
None of the functions in the Test or Ctrl branches
are available.
•
All functions on the Stat branch are available.
•
All functions on the Cnfg branch are available for
display, but they cannot be used to save to a
configuration area (Activ, Cust1, Cust2, or Fact).
You can only reach the screen that controls security
access using the front panel.
Changing User Interface Access Security
To change user interface access security,
1. Press the key two times from the top-level
screen.
F1
DSU E1 CEPT
Stat
Test Cnfig
F2 F3
2. Press the key three times.
F1
DSU E1 CEPT
Stat
Test Cnfig
F2 F3
3. Press the key once.
F1
DSU E1 CEPT
Stat
Test Cnfig
F2 F3
The Security screen appears.
F1
Security:
Lvl1
Lvl2
F2 F3
4. Press F1 to select Lvl1, or press F2 to select Lvl2.
After you make a selection, the top-level screen
appears.
If you do not make a selection within 5 minutes,
the Automatic Device Health/Status screen
appears.
