Paradyne ACCULINK 317x E1 User Manual
Page 15
ACCULINK 317x E1 DSU/CSU
2-2
December 1996
3170-A2-GB20-20
NETWORK
SERVICES
PBX
LAN
ROUTER
496-14312-03
DSU/CSU
Figure 2-2. Shared Access Application Example
FRACTIONAL
NETWORK
LAN
ROUTER
LAN
ROUTER
LAN
ROUTER
496-14313-03
DSU/CSU
DSU/CSU
DSU/CSU
LAN
ROUTER
Figure 2-3. Fractional E1 Application Example
496-14700-01
DACS
MOBILE SWITCH
MOBILE SWITCHING
CENTER
CELL SITE
CELL SITE
WIRELESS
WIRELESS
DSU/CSU
DSU/CSU
Figure 2-4. Wireless/DACS Application Example
