background image

Operation

3-5

3170-A2-GB20-20

December 1996

Table 3-1

System LEDs

Name

Color

Meaning

OK

Green

Indicates the current operational state of the E1 DSU/CSU.

ON :

The E1 DSU/CSU is operational and has power.

OFF :

The E1 DSU/CSU is performing a power-up self-test or a system
failure has occurred.

BLINKING :

A software download is in progress.

FAIL

Yellow

Indicates a system failure or a self-test.

ON :

A device error/fault is detected or a reset has just occurred.

OFF :

No system failures are detected.

BLINKING :

A self-test is in progress.

TEST

Yellow

A system test is in progress.

ON :

A loopback or pattern test has been initiated either locally, by the
network, or externally.

OFF :

No tests are active.

Table 3-2

NETWORK Interface LEDs

Name

Color

Meaning

SIG

Green

Monitors the signal being received from the network.

ON :

A recoverable signal is being received from the network.

OFF :

The signal cannot be recovered from the network (a Loss of Signal
condition exists).

OOF

Yellow

Monitors Out Of Frame (OOF) conditions on the received network signal.

ON :

At least one OOF was detected on the signal during the sampling
period.

OFF :

No OOFs were detected on the signal during the sampling period.

ALRM

Yellow

Indicates whether an alarm condition exists on the received network signal.

ON :

An alarm condition (LOS, LOF, EER, RAI, AIS) exists on the
received network signal. Use the Device Health and Status
command to determine the alarm type.

OFF :

No alarm condition exists on the network interface signal.

EER

Yellow

Indicates when the excessive error rate has been exceeded on the network
interface.

ON :

The excessive error rate has been exceeded on the network
interface.

OFF :

The excessive error rate has not been exceeded on the network
interface.
