Paradyne ACCULINK 317x E1 User Manual
Page 147
E-17
3170-A2-GB20-20
December 1996
Table E-1
(2 of 3)
SNMP MIB to Front Panel Command Cross-Reference
Front Panel Command
SNMP MIB Object
Stat–>Tstat:
LLB Test Active
PLB Test Active
RLB Test Active
DLB Test Active
DCLB on Port
n
DTLB on Port
n
1–8 Test Active
QRSS on Port
n
511 on Port
n
Mon QRSS, Port
n
Mon511, Port
n
Read:
dsx1LineLoop from dsx1LoopbackConfig for Net E1
dsx1PayloadLoop from dsx1LoopbackConfig for Net E1
dsx1PayloadLoop from dsx1LoopbackConfig for DTE E1
dsx1LineLoop from dsx1LoopbackConfig for DTE E1
testFullDuplexLoopback from IfExtnsTestType for Port n
testLoopDTLB from IfExtnsTestType for Port n
testSend1in8 from ifExtnsTestType for Net E1
testSendQRSS from IfExtnsTestType for Port n
testSend511 from IfExtnsTestType for Port n
testMonQRSS from ifExtnsTestType for Port n
testMon511 from ifExtnsTestType for Port n
Stat–>LED–>Prtn:
DTR
CTS
RTS
Read:
rs232InSigState from rs232InSigName == dtr
rs232outSigState from rs232OutSigName == cts
rs232InSigState from rs232InSigName == rts
Stat–>ID:
Ser
Mod
SRev
HRevCCA1
HRevCCA2
Read the sysDescr object from the System Group
Test–>Rlpbk–>DCLBUP–>Prt
n
Set IfExtnsTestType for port
n to testSendV54Up
Test–>Rlpbk–>DCLBDN–>Prt
n
Set IfExtnsTestType for port
n to testSendV54Down
Test–>Lpbk–>LLB
Test–>Lpbk–>Abort–>LLB
Set dsx1LoopbackConfig for Net E1 to
dsx1LineLoop
Set dsx1LoopbackConfig for Net E1 to
dsx1NoLoop
Test–>Lpbk–>PLB
Test–>Lpbk–>Abort–>PLB
Set dsx1LoopbackConfig for Net E1 to
dsx1PayloadLoop
Set dsx1LoopbackConfig for Net E1 to
dsx1NoLoop
Test–>Lpbk–>DLB
Test–>Lpbk–>Abort–>DLB
Set dsx1LoopbackConfig for DTE E1 to
dsx1LineLoop
Set dsx1LoopbackConfig for DTE E1 to
dsx1NoLoop
Test–>Lpbk–>RLB
Test–>Lpbk–>Abort–>RLB
Set dsx1LoopbackConfig for DTE E1 to
dsx1PayloadLoop
Set dsx1LoopbackConfig for DTE E1 to
dsx1NoLoop
Test–>Lpbk–>DCLB–>Prt
n
Test–>Lpbk–>Abort–>DCLB–>Prt
n
Set IfExtnsTestType for port
n to testFullDuplexLoopBack
Set dsx1LoopbackConfig for port
n to noTest
Test–>Lpbk–>DTLB–>Prt
n
Test–>Lpbk–>Abort–>DTLB–>Prt
n
Set IfExtnsTestType for port
n to testLoopDTLB
Set dsx1LoopbackConfig for port
n to noTest
Test–>Ptrns–>Send–>QRSS–>Prt
n
Test–>Ptrns–>Abort–>Send–>Prt
n
Set IfExtnsTestType for port
n to testSendQRS
Set IfExtnsTestType for port
n to noTest
Test–>Ptrns–>Send–>1in8
Test–>Ptrns–>Abort–>Send–>NET
Set ifExtnsTestType for Net E1 to
testSend1in8
Set dsx1SendCode for Net E1 to
dsx1SendNoCode
