ACCULINK 317x E1 DSU/CSU
E-16 December 1996 3170-A2-GB20-20
Correlation between Menu
Commands and SNMP Objects
Table E-1 provides a correlation between how a
function is performed or status is displayed on the front
panel and how the same function is accomplished using
access to the SNMP database. SNMP objects are
displayed in bold type while values for SNMP objects are
displayed in italics.
Table E-1
(1 of 3)
SNMP MIB to Front Panel Command Cross-Reference
Front Panel Command SNMP MIB Object
Stat–>DevHS:
LOS at NET
OOF at NET
RAI at NET
AIS at NET
EER at NET
Read the dsx1LineStatus object for NET E1
dsx1LossOfSignal
dsx1LossOfFrame
dsx1RcvFarEnd
dsx1RcvAIS
dsx1OtherFailure
Stat–>DevHS:
LOS at DTE
OOF at DTE
RAI at DTE
AIS at DTE
Read the dsx1LineStatus object for DTE E1
dsx1LossOfSignal
dsx1LossOfFrame
dsx1RcvFarEnd
dsx1RcvAIS
Stat–>Perf–>NET–>Cur:
CurTimer
ES
UAS
SES
BES
Read the value in following objects for NET E1
dsx1TimeElapsed
dsx1CurrentES
dsx1CurrentUAS
dsx1CurrentSES
dsx1CurrentBES
Stat–>Perf–>NET–>Intvl–>Dsply:
ES
UAS
SES
BES
VldIntvl
Select the interval number with dsx1IntervalNumber. Read the value
in the following objects for the NET E1
dsx1IntervalES
dsx1IntervalUAS
dsx1IntervalSES
dsx1IntervalBES
dsx1ValidIntervals
Stat–>Perf–>NET–>24Tot:
VldIntvl
ES
UAS
SES
BES
Read the value in the following objects for NET E1
dsx1ValidIntervals
dsx1TotalES
dsx1TotalUAS
dsx1TotalSES
dsx1TotalBES
