ACCULINK 317x E1 DSU/CSU
C-24 December 1996 3170-A2-GB20-20
Prt1 Options Value
Port Type E530, V.35, RS449
Base Rate Nx64, Nx56
NetDCLB Enab, Disab
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv RAI None, Halt
Tx Clock Int, Ext
InvertTxC Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E–4, 10E–5, 10E–6, 10E–7,
10E–8, 10E–9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Disab, SNMP
Prt2 Options Value
Port Type E530, V.35, RS449
Base Rate Nx64, Nx56
NetDCLB Enab, Disab
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv Yellow None, Halt
Tx Clock Int, Ext
InvertTxC Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E–4, 10E–5, 10E–6, 10E–7,
10E–8, 10E–9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Disab, SNMP
Prt3 Options Value
Port Type E530, V.35, RS449
Base Rate Nx64, Nx56
NetDCLB Enab, Disab
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv Yellow None, Halt
Tx Clock Int, Ext
InvertTxC Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E–4, 10E–5, 10E–6, 10E–7,
10E–8, 10E–9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Disab, SNMP
Prt4 Options Value
Port Type E530, V.35, RS449
Base Rate Nx64, Nx56
NetDCLB Enab, Disab
Port LB Disab, DTLB, DCLB, Both
All Ones Disab, DTR, RTS, Both
Rcv Yellow None, Halt
Tx Clock Int, Ext
InvertTxC Enab, Disab
InvrtData Enab, Disab
EDL Enab, Disab
Err Rate 10E–4, 10E–5, 10E–6, 10E–7,
10E–8, 10E–9
Near-end Disab, Maint, Send, Both
Far-end Disab, Maint
Mgmt Link Disab, SNMP
