ACCULINK 317x E1 DSU/CSU
E-18
December 1996
3170-A2-GB20-20
Table E-1
(3 of 3)
SNMP MIB to Front Panel Command Cross-Reference
Front Panel Command
SNMP MIB Object
Test–>Ptrns–>Send–>511–>Prt
n
Test–>Ptrns–>Abort–>Send–>Prt
n
Set IfExtnsTestType for port
n to testSend511
Set IfExtnsTestType for port
n to noTest
Test–>Ptrns–>Mon–>QRSS–>Prt
n
Test–>Ptrns–>Abort–>Mon–>Prt
n
Set ifExtnsTestType for port
n to testMonQRSS
Set ifExtnsTestType for port
n to noTest
Test–>Ptrns–>Mon–>511–>Prt
n
Test–>Ptrns–>Abort–>Mon–>Prt
n
Set ifExtnsTestType for port
n to testMon511
Set ifExtnsTestType for port
n to noTest
Cnfig–>Load Cnfig–>Save
Set devConfigAreaCopy to desired choice (Active to Customer1, etc.)
Cnfig–>Activ–>Edit–>DTE–>DTE–>Frame
Set/Display dsx1LineType for DTE E1 to
dsx1E1 or dsxE1-CRC
Cnfig–>Activ–>Edit–>DTE–>DTE–>Coding
Set/Display dsx1LineCoding for DTE E1 to
dsx1HDB3 or dsx1AMI
Cnfig–>Activ–>Edit–>Port–>Prtn->Port Type
Display rs232PortType for port
n to rs422 or v35
Cnfig–>Activ–>Edit–>Port–>Prt
n–>TxClock
Set/Display rs232SyncPortClockSource for port
n to internal or
external
Cnfig–>Activ–>Edit–>NET–>NET Frame
Set/Display dsx1LineType for NET E1 to
dsx1E1 or dsxE1-CRC
Cnfig–>Activ–>Edit–>NET–>Mgmt Link
Set/Display dsx1Fdl for NET E1 to
dsx1other or dsx1FDL-none
Cnfig–>Activ–>Edit–>Chan–>DTE–>Assign
Set/Display dsx1FracNumber and dsx1FracIfindex for DTE E1
Cnfig–>Activ–>Edit–>Chan–>DTE–>TS16
Display dsx1SignalMode for DTE E1 to
none or messageOriented
Cnfig–>Activ–>Edit–>Chan–>Prt
n–>Assign To
Cnfig–>Activ–>Edit–>Chan–>Dsply
Set/Display dsx1FracNumber and dsx1Fracifindex for DTE or
NET E1
Cnfig–>Activ–>Edit–>Chan–>Prt
n–>Port Rate
Display rs232PortInSpeed or rs232PortOutSpeed for port
n
Cnfig–>Activ–>Edit–>Gen–>Pri Clk Src
Cnfig–>Activ–>Edit–>Gen–>Sec Clk Src
Display dsx1TransmitClockSource for DTE E1 or NET E1 (Displays
the active clock only)
Cnfig–>Activ–>Edit–>User–>Com Rate
Cnfig–>Activ–>Edit–>User–>Aux Rate
Set/Display rs232PortInSpeed or rs232PortOutSpeed for COM or
AUX port
Cnfig–>Activ–>Edit–>User–>Char Length
Set/Display rs232AyncPortBits for COM port
Cnfig–>Activ–>Edit–>User–>CParty
Set/Display rs232AyncPortParity for COM port
Cnfig–>Activ–>Edit–>User–>CStop Bits
Set/Display rs232AyncPortStopBits for COM port
