Operation
3-31 3170-A2-GB20-20 December 1996
7. From the DTE Channels screen, press F1 to select
TS16.
F1
DTE Channels:
TS16
Assign
F2 F3
8. Rsvd (Reserved) is the default for TS16. This
indicates that time-slot 16 is reserved for signaling
information. Pressing F1 (Data) makes
time-slot 16 available for data.
F1
TS16:Rsvd
Data
Rsvd
F2 F3
NOTE
If TS16 is reserved for signaling,
D16 will automatically be
assigned to N16, and DTE DS0
channels allocated to the network
interface must be connected to
the corresponding channel (e.g.,
D1 to N1, D2 to N2, etc.).
9. Press from the TS16 screen to return to the
DTE Channels screen.
F1
TS16:Rsvd
Data
Rsvd
F2 F3
10. From the DTE Channels screen, press F2 to select
Assign.
F1
DTE Channels:
TS16
Assign
F2 F3
11. Press the Function key below the network channel
desired. Each time that you press the Function key,
the DTE channel number will scroll up one
number. If the network channel is currently
unassigned (‘‘–” is displayed on Line 2), the DTE
channel number initially displays the same number
as the corresponding network channel number.
However, if the network channel is currently
assigned, the DTE channel number is shown as
Dn. Pressing the Function key for D31 wraps the
display back to D1. Only those channels that are
not already assigned will appear on the LCD when
scrolling. The network channels assigned to ports
(Prt1...Prt4) are unavailable for assignment.
F1
N1 N2 N3
D1 D2 –
F2 F3
