Paradyne ACCULINK 317x E1 User Manual
Page 17
ACCULINK 317x E1 DSU/CSU
2-4
December 1996
3170-A2-GB20-20
NETWORK
LAN
ROUTER
ETHERNET
SNMP
PPP
496-14548a
LAN
ADAPTER
DSU/CSU
SNMP
NMS
Figure 2-7. Connection through a LAN Adapter to SNMP
LAN
ROUTER
ETHERNET
SNMP
PPP
496-14549a
LAN
ADAPTER
SNMP
PPP
SNMP
PPP
NETWORK
DSU/CSU
DSU/CSU
DSU/CSU
SNMP
NMS
Figure 2-8. LAN Adapter and Daisy Chaining for SNMP Support
LAN
ROUTER
ETHERNET
SNMP
FDL/EDL
SNMP
PPP
496-14550a
NETWORK
LAN
ADAPTER
DSU/CSU
DSU/CSU
Figure 2-9. Remote SNMP Management through FDL/EDL
