ACCULINK 317x E1 DSU/CSU
D-4 December 1996 3170-A2-GB20-20
AUX Port Interface
The Auxiliary (AUX) port connects to the SNMP LAN
Adapter for SNMP applications, or to another E1
DSU/CSU’s COM port for daisy chain connectivity. (The
SNMP LAN Adapter includes the cable that is needed
to attach it to the E1 DSU/CSU.) The AUX port
connector is an 8-pin modular connector (Table D-3).
NOTE
For daisy-chaining an AUX port
to a COM port, a customer
supplied, 8-pin-to-8-pin, straight-
through cable is required and
the appropriate configuration
options (Com Use and Aux Use)
must be set to Daisy. Whenever
the cable is connected or
disconnected, you should
change the Daisy selection to
ensure that the correct
parameters have been
negotiated for the link layer.
Table D-3
AUX Port Connector
Signal Direction Pin Number
DTE Transmit Clock From DSU/CSU 1
DTE Receive Data To DSU/CSU 2
Signal Ground — 3
DTE Transmit Data From DSU/CSU 4
DTE Receive Clock From DSU/CSU 8
