ADJUSTMENTS
3. GENERAL EXAMPLES OF MULTI PROJECTION PRESENTA-
TIONS
(1) Switching between enlarged/individual display on the multi video
processor
(2) Switching the sources input to the multi video processor
Source
NTSC NTSC
Multi video
processor Multi projection
unit
LDP-1
LDP-2
Multi video
processor
NTSC
Y/C
or
RGB
Multi projection
unit
TV SYSTEM) AUTO
Convergence data required for presentation) 1 set
* There is a phase
difference between
LDP-1 and LDP-2.
* There is only one
set of frame data.
TV SYSTEM) AUTO
Convergence data required for presentation) 2 sets
* For example, LDP-1 adjusted by MEMORY-1,
LDP-2 adjusted by MEMORY-3, data switching by
external control when LDP switched
