165
MVP MANUAL
*6 : Display of remote and manual states
REMOTE MODE : Remote state
MANUAL MODE : Manual state
*7 : Slot number
*8 : Type of input board
NTSC BOARD : NTSC input board
V.SCAN BOARD : Variable scan board (option)
NO BOARD : No input board is incorporated
*9 : NTSC input board state
STANDARD MODE : When standard NTSC signal is input
NO STANDARD MODE : When non-standard NTSC signal is input
*10: Display of VBS/ Y/C select switch state
VBS : Composite video signal input (Indicates V FIL.ON for the V.SCAN BOARD)
Y/C : Y/C separation signal input (Indicates V FIL.OFF for the V.SCAN BOARD)
*11: Type of output board
4 OUT BOARD : 4 output board
NO BOARD : No output board is incorporated
5. To perform NTSC input board picture quality adjustment
(1) To set the adjustment mode [AJYC command]
(2) To exit the adjustment mode [AJN command]
Input: AJYC , AJN
Explanation: AJYC command : Sets the NTSC input board to the adjustment mode.
AJN command
: Exists the adjustment mode.
• When adjusting the NTSC input board, the adjustment command will be ignored if AJYC is not
executed.
* To set the optional variable scan board to the adjustment mode:
: Use the :A command. (Refer to page 171 and on.)
