131
ADJUSTMENTS
8) 4
• Selects 4 (CONVERGENCE ADJUST MODE) of the main menu of the adjustment mode.
• Selects “4” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Cyclically switches COLOR MODE 1/2 in the OPERATION MODE.
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 SKEW 3 3D SKEW 3 5D SKEW
• Moves the point to be adjusted to the left in the POINT CONVER ADJUST MODE.
• Selects TINT in the WHITE BALANCE ADJUST MODE(,only invalid for RGB and PAL signal input).
• Select the pattern (2 =3) for copying the convergence data between memories in the MEMORY READ/
COPY MODE.
9) 5
• Selects 5 (POINT CONVERGENCE ADJUST MODE) of the main menu of the adjustment mode.
• Selects “5” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE, or clear the ID number in the ID
clear mode.
• Cyclically switches COMBINATION ON/OFF in the OPERATION MODE.
• Selects H SIZE in the DEFLECTION ADJUST MODE.
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 KEY 3 MID KEY 3 3D KEY 3 MID 3D KEY
• Selects SHARPNESS in the WHITE BALANCE ADJUST MODE(,only invalid for RGB input).
• Select the pattern (3
=1) for copying the convergence data between memories in the MEMORY READ/
COPY MODE.
10) 6
• Selects 6 (WHITE BALANCE ADJUST MODE) of the main menu of the adjustment mode.
• Selects “6” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Cyclically switches VIDEO MUTE ON/OFF in the OPERATION MODE.
• Selects V LINEARITY in the DEFLECTION ADJUST MODE.
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 SUB KEY 3 MID SUB KEY 3 3D SUB KEY 3 MID 3D SUB KEY
• Moves the point to be adjusted to the right in the POINT CONVER ADJUST MODE.
• Selects LINEAR WHITE in the WHITE BALANCE ADJUST MODE.
• Select the pattern (3 =2) for copying the convergence data between memories in the MEMORY READ/
COPY MODE.
11) 7
• Selects 7 (MEMORY READ MODE) of the main menu of the adjustment mode.
• Selects “7” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Cyclically selects the RS-232C baud rate in the OPERATION MODE in the following order.
3 1200 3 2400 3 4800 3 9600 3 19200
• Selects H BLK-L in the DEFLECTION ADJUST MODE.
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 BOW 3 4D BOW 3 6D BOW
• Selects RED HIGHLIGHT in the WHITE BALANCE ADJUST MODE.
