40
INSTALLATION AND ASSEMBLY
4. ASSEMBLING THE SYSTEM
(1) System assembly flowchart
Fix the adjusters.
Fix a cabinet on the projection stand.
With a 9-screen system, connect the
cabinet for the third stage after
connecting that for the second stage.
Do you install the system up against
the wall?
Perform the system wiring on the
rear.
Check power supply operation, etc.
Arrange the required number of
cabinets horizontally and connect
them between each other.
Connect the screen frames vertically.
Hook the screens on the cabinets (all).
Fix the screen frames and cabinets.
Connect the
cabinet for the
second stage.
Move the system
(up against the wall).
3-stage configuration
2-stage configuration
YES
NO
Prevent tumbling down and fix the
anchors.
