190
MVP MANUAL
• Matrix screen no.
Indicates the position of the output screen that will become the top-left corner of the magnified
display.
When this is outside of the 64 actual screens, you should consider the 256 imaginary screens
shown in the diagram below. In this case, the screen nos. are as follows.
11~88: Matrix display area of the 64 actual screens
91-F8: Imaginary screens (the 64 screens to the left of the actual screens)
19-8F: Imaginary screens (the 64 screens above the actual screens)
99~FF: Imaginary screens (the 64 screens above and to the left of the actual screens)
Standard screen for the 256 imaginary screens
Actual screens
Actual screens
99 A9 B9 C9 D9 E9 F9 19 29 39 49 59 69 79 89
9A AA BA CA DA EA FA 1A 2A 3A 4A 5A 6A 7A 8A
9B AB BB CB DB EB FB 1B 2B 3B 4B 5B 6B 7B 8B
9C AC BC CC DC EC FC 1C 2C 3C 4C 5C 6C 7C 8C
9D AD BD CD DD ED FD 1D 2D 3D 4D 5D 6D 7D 8D
9E AE BE CE DE EE FE 1E 2E 3E 4E 5E 6E 7E 8E
9F AF BF CF DF EF FF 1F 2F 3F 4F 5F 6F 7F 8F
91 A1 B1 C1 D1 E1 F1 11 21 31 41 51 61 71 81
92 A2 B2 C2 D2 E2 F2 12 22 32 42 52 62 72 82
93 A3 B3 C3 D3 E3 F3 13 23 33 43 53 63 73 83
94 A4 B4 C4 D4 E4 F4 14 24 34 44 54 64 74 84
95 A5 B5 C5 D5 E5 F5 15 25 35 45 55 65 75 85
96 A6 B6 C6 D6 E6 F6 16 26 36 46 56 66 76 86
97 A7 B7 C7 D7 E7 F7 17 27 37 47 57 67 77 87
98 A8 B8 C8 D8 E8 F8 18 28 38 48 58 68 78 88
• Any designations in the shaded area are invalid.
Moreover, a designation of an imaginary screen (e.g. M99A77) is invalid if the magnified region
does not fall within the actual screen area.
• Please ensure that you designate the matrix screen no. in such a way that designated display
region falls within the actual screen area.
